150-300 Bar Inert Gas Argonite IG100 Fire Suppression System

Name: 150300 Bar Inert Gas Argonite IG100 Fire Suppression System
Brand: Air Giant
Price: 1 USD

Brand Name : Air Giant

Model Number : QMD20/80, QMD30/80

Certification : CAL,CMA,CNAS,ILAC-MRA,CCC

Place of Origin : China

MOQ : 1 set

Price : negotiation

Payment Terms : L/C , D/P, T/T, Western Union, Paypal, Credit card

Supply Ability : 300 sets per month

Delivery Time : 10-15 working days

Packaging Details : Plywood outer box with bubble bag or paper

Cylinder Volume : 80L,140L

Pattern of extinguishing : Enclosed flooding

Agent : IG100(100% pressurized nitrogen)

Working pressure : 20MPa, 30MPa

Max. working pressure : 23.2MPa, 36.6 MPa

System start mode : Electrical automatic, electrical manual, mechanical emergency star

Color : Red

Contact Now

150-300 Bar Inert Gas Argonite IG100 Fire Suppression System Be Widely Used

Description

IG-100 uses Nitrogen for a clean, safe and 100% ecological extinguishing. This gas is widely used in variety of extinguishing systems due to its excellent pressurization conditions.

In this case it complies with equal smothering efficiency by reducing the oxygen concentration to extinguish the fire, while leaving a percentage of oxygen suitable for occupied areas. Because of this feature, people can be protected where there is the possibility if they are in the enclosure area at the time of the fire, ensuring their safe evacuation both in terms of the level of oxygen in the room, and the absence of chemicals in the discharge. In addition, its physical and dispersion properties help maintain visibility during the evacuation.

Parameters

Executive standard of IG100 fire suppression system		GB25972-2010 Gas extinguishing system and components
Working temperature (℃)		0℃～+50℃
Working pressure	Storage pressure	20.0 MPa
	Max. working pressure (+50℃)	23.2 MPa
	Min. working pressure (-20℃)	18 MPa
Container volume (L)		80L	140L	180L
Filling weight (kg, @200 bar)		18.38kg	31.3kg	40.32kg
System operating voltage		220V AC,24V DC
System start mode		Electrical automatic, electrical manual, mechanical emergency start
Fire extinguishing concentration	Class A dangerous material surface fire	31%
	Normal heptane	33.6%
Design concentration	Class A dangerous material surface fire	40.3%
	Normal heptane	43.7%
The design concentration of the protective zone with people working		37.5～43%

Components

150-300 Bar Inert Gas Argonite IG100 Fire Suppression System

Application

- Computer rooms

- Telecommunication center

- Facilities underground

- Offshore oil extraction

- Library

- Data and paper archives

- Valuable article storage

- Power generator storage room

150-300 Bar Inert Gas Argonite IG100 Fire Suppression System

Advantages

Suitable for occupied areas
Electrically non – conductive
Chemically inert
Colourless, odourless and flavourless
No residue to clean up after the discharge
Zero Ozone Depletion Potential (ODP)
No greenhouse effect
No global warming iMPact
No decomposition products
No fog and no loss of post-discharge visibility
Non corrosive/toxic
Stored as a gas
Excellent post-discharge visibility
Very low refill cost.
Easy to obtain anywhere in the world

Packages

We always pack it with polyfoam first and then put it into a wooden case. Sometimes, in order to meet with customers or the safety requirement, we will make a pallet for the goods.

150-300 Bar Inert Gas Argonite IG100 Fire Suppression System
